Diesel Welding Generator 4.6kW - 180A

Description

TOTAL Diesel welder generator (TP446001)

TOTAL TP446001 is a versatile powerhouse designed for the most demanding remote environments. Combining a robust diesel generator with an arc welder, this unit provides the high-wattage power needed for tools and lighting while simultaneously serving as a high-performance welding station.

Key Features:

• Reliable Diesel Power: 9.0HP 418cc air-cooled diesel engine offers superior fuel efficiency and longevity compared to gasoline alternatives
• Pure Copper Coil Alternator: Ensures stable power delivery, higher conductivity, and better heat resistance for continuous professional use
• Dual Starting System: Features both Electric Start (with a 30AH maintenance-free battery) and a reliable Recoil backup

Welding & Power Capabilities

• Broad Welding Range: Adjustable current from 50A to 180A, capable of handling electrodes from 1.6mm up to 4.0mm
• Reliable AC Output: Delivers a maximum of 4.6kW (220-240V), perfect for powering heavy-duty grinders, drills, and site lighting
• DC Output: Includes a 12V (8.3A) output for battery charging and low-voltage accessories

Technical Specifications:

• Generator
• Rated Frequency: 50Hz
• Rated Power: 4.2kW
• Rated Voltage: 220V - 240V
• Rated Current: 18.3A
• Phase No: Single
• Power Factor: 1.0
• DC output: 12V, 8.3A
• Insulation Class: F
• Welder
• Max Welding Current: 180A
• Welding Voltage: 55-65V
• Duty Cycle: 60%
• Current Range: 50A - 180A
• Electrode Diameter: 1.6mm - 4.0mm
• Note: No welding accessories included
• Engine
• Engine Type: Air-cooled Diesel engine
• Power Output: 9.0HP
• Displacement: 418cc
• Rated Speed: 3000/min
• Fuel Capacity: 15L
• Starting system: Recoil + Electric

Attention: Generator is shipped dry, please add fuel and oil before starting the engine
Please read and follow the instructions carefully before operation
